Standard Halnn RCMX1207 Y type CBN Inserts Heavy Turning High speed steel Rolls
1. Halnn Tools Standard Halnn RCMX1207 Y type CBN Inserts Heavy Turning High speed steel Rolls
BN-S10 grade CBN tool processing advantages in the field of hardness casting rolls:
(1) The use of non-metallic ceramics as a binder can ensure the high hardness and high wear resistance of the cubic boron nitride cutter, and also improve the impact toughness and fracture resistance;
(2) BN-S10 grade belongs to the whole polycrystalline cubic boron nitride tool, which overcomes the limitation of cutting depth and avoids the risk of failure of cubic boron nitride tool;
(3) The large margin cuts the remaining amount of the roll blank to improve the processing efficiency and reduce the production cost.
2.CBN ToolS Characteristics
| ISO Code | Insert Grade | Suited Materials | Advantages | Application Industry |
| K/S | BN-K1 | Chilled Cast Iron | Good Collapse Resistance | Cast Iron Rolls |
| Wear Resistant Cast Iron | Excellent Fracture Resistance | Pump |
| High Manganese Steel |
| H | BN-S20 | Hardened Steel | Excellent Wear Resistance | Hardened Steel Rolls |
| Rolled Hardened Steel | Good Thermal Shock Resistance | Ball Screw |
| Wear Resistant and Heat-resistant Steel | Wind Power Bearings |
| Wear Resistant Castings |
| K | BN-S30 | Cast Iiron | Good Impact Resistance | Automotive Parts,Brake Discs/Drum |
| Hard Cutting Material | Excellent Wear Resistance | Pump Parts |
| K | BN-S300 | Cast Iron Iron Series | Good Keeness | Cast Iron Engine Block |
| Sintered Alloy | Gearbox Housing |
| Engine Cylinder liner |
| H | BN-S200 | Hardened Steel | Excellent Wear Resistance | Slewing Bearings |
| Superalloy | Forged Steel Chilled Rolls |
| K | BNK30 | Cast Iron | Excellent Wear Resistance | Automotive Parts,Brake Discs/Drum |
3.Detailed Data of RCMX CBN inserts
 |
| Type | Dimension | Standard Chamfer | Grades |
| L(mm) | φI.C(mm) | S(mm) | b(mm) | S01020 S02020 S03020 S05020 S10020 S20020 | BN-K1 | BN-S20 | BN-S200 | BN-S300 | BN-S10 |
| RCMX191000V | | 19.05 | 10 | 2 | ● | ● | ◎ | ◎ | ● |
| RCMX201200V | | 20 | 12 | 2 | ● | ● | ◎ | ◎ | ● |
4.Application Case
5.FAQ
1. Are you a trading company or manufacturer ?
A: We are a manufacturer and wholesaler for pcd & CBN (cubic boron nitride) tools.
2. How long is your delivery time?
A: Generally it is 7-12 days.
2. Do you provide samples ? Is it free or extra ?
A: Normally we do not offer free samples, we could offer the sample for testing, but shipping fee is to be paid by customer as a company policy!
